Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction machines. They manufacture machinery like aerial lifts, manlifts and boom lifts. These machinery are designed to facilitate access to hard to reach places, buildings and roofs, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt only moves in one direction and contains handholds or platforms or steps that are attached to the unit to be able to move employees from every floor.
TB85
The Terex TB85 offers a maximum working height of 91 feet. In addition, the platform's maximum height reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of 70 feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The maximum width of the unit is 8 feet, 1 1/2 inches. The boom angle below horizontal is -14 degrees and above horizontal is 75 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall measures at 116 feet. When stowed, this model is 9 feet, 4 inches high x 8 feet wide. The TB110 offers a maximum width of 8 feet and a horizontal reach of 67 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
